If electric current passing through a conductor vanes with time as I = I0 + βt, where I0 = 20A,β = 3A/s, then find charge flow through conductor in first 10 sec.

∫ I . d t = ∫ 0 1 0 ( 2 0 + 3 t ) d t = ( 2 0 t ) 0 1 0 + 3 ( t 2 2 ) 0 1 0 = 3 5 0 C

If electric current passing through a conductor vanes with time as I = I0 + βt, where&nbsp;I0 = 20A,β = 3A/s, then find charge flow through conductor in first 10 sec.

350 C

400 C

500 C

200 C

Ask & Answer Question

Overview Physics Current Electricity Physics Class 12th

If electric current passing through a conductor vanes with time as I = I₀ + βt, where I₀ = 20A,β = 3A/s, then find charge flow through conductor in first 10 sec.

Option 1 -

400 C

Option 2 -

500 C

Option 3 -

200 C

Option 4 -

350 C

2 Views | Posted 3 days ago

Asked by Shiksha User

1 Answer

Answered by

alok kumar singh | Contributor-Level 10

3 days ago

Correct Option - 4

Detailed Solution:

$\int I . d t = \int_{0}^{10} (20 + 3 t) d t$

$= {(20 t)}_{0}^{10} + 3 {(\frac{t^{2}}{2})}_{0}^{10} = 350 C$

0 Upvotes 0 Downvotes

Similar Questions for you

Two identical cells connected in series send 10 A current through a 5 W resistor. When they are connected in parallel, they send 8 A current through same resistance. What is internal resistance of each cell?

alok kumar singh

In the shown circuit, current through 4 Ω resistor is

alok kumar singh

It is balanced wheatstone bridge

An ideal engine whose efficiency is 40%, receives heat at 500 K. If required efficiency is 50%, then intake temperature for the same exhaust temperature is

alok kumar singh

Consider the circuit shown. Galvanometer resistance is 10 Wand current through galvanometer is 3 mA. Find the resistance of shunt.

alok kumar singh

Since Gand S are in parallel

-> V_G = V_S

->3mA * 10 = 8A * R_S

->R_S = 3.75mW

A square loop of resistance 16 Wis connected with battery of 9 V and internal resistance of 1W. In steady state, find energy stored in capacitor of capacity c = 4 mF as shown (at steady state current divides. symmetrically)
