Two 10cm log, straight wires, each carrying a current of 5A are kept parallel to each other. If each wire experienced a force of 10^-5N, then separation between the wires is__________cm.

2 Views | Posted 3 months ago

Asked by Shiksha User

1 Answer

Answered by

Vishal Baghel | Contributor-Level 10

3 months ago

$F = \frac{μ_{0} \times 2}{4 π} \frac{i_{1} i_{2}}{d} l$

$1 0^{- 5} = \frac{1 0^{- 7} \times 2 \times 5 \times 5}{d} = \frac{10}{100}$

$d = 5 \times 1 0^{- 2} m$

d = 5 cm

0 Upvotes 0 Downvotes
